Overview

Arducam's V3Link camera kit boasts a Full HD IMX219 sensor following the V3Link protocol, standing as the prime choice for high-bandwidth, long-range vision projects. Its shielded coaxial cable ensures dependable power and data transmission up to 10m, maintaining low latency for optimal performance.

Featuring 4× 8MP camera modules, this kit allows flexible channel switching or independent control. Achieving both multi-camera synchronization and remote control, it offers unparalleled flexibility and convenience.

V3Link, a high-bandwidth transmission interface developed by Texas Instruments, leverages FPD-Link's IP for ADAS, security cameras, industrial, and medical imaging. Empowering Arducam's camera kit, ensures efficient data transmission, making it a robust choice for various applications and long-distance connections.

Applications

• ADAS
• Automotive
• Security Cameras
• Industrial Systems
• Medical Imaging

Features

• TI SK-AM62A-LP Compatibility: Tailored for TI SK-AM62A-LP/AM68A/AM69A development board, offering a multi-camera solution with high bandwidth for extended-distance transmission.
• IMX219 CMOS & Long-Range Stability: Utilizes the IMX219 8MP sensor for high-quality imaging. Achieves stable cable connections up to 10 meters with multi-camera synchronization.
• Flexible Channel Management: Enables channel switching and independent control, supporting up to four cameras. High-frequency signal transmission facilitates versatile applications like automotive, surveillance, medical, and industrial imaging.
• Cost-Effective 4-Channel System: Allows the creation of a synchronized 4-channel vision system, reducing development costs. Ideal for various applications, ensuring a smaller footprint and flexible deployment.
• Plug-and-Play Convenience: Effortless setup with no additional configuration or drivers required. Streamlines the integration process for quick and hassle-free deployment in diverse scenarios.

Specifications

Package Including

• 1× Arducam V3Link d-ch Rx board
• 4× Arducam V3Link camera Tx board
• 4× 1m Fakra Z Female to Female RF Coaxial Cable
• 4× Arducam IMX219 Camera Module
• 4× 40cm 22-22pin FPC Cable
• 1× 15cm 22-22pin FFC Cable
• 1× Power Adapter

Notes

• TI development board is not included in the package.
• This kit includes IMX219 camera modules and cannot be mixed with other sensors.
• The V3LINK solution also supports other camera modules, please contact sales for more details.

Documentation

• Quick Start Guide
• V3Link Camera Solution
• V3Link Camera Solution Datasheet
