Meet the all-new Sketch Classroom, the comprehensive 3D printer solution designed to accelerate learning and design-thinking.
Featuring a dual-printer set up, educators can offer the ideal student-to-printer ratio to drive 3D printing classroom success right from the start.
With teacher and student certifications and more than 600+ lesson plans included, educators can integrate more interactive design projects and increase student engagement.
Classroom 3D printer management is easier than ever with one queue management dashboard via MakerBot Cloud. Students can share design projects wirelessly and teachers can manage queues easily between printers.
| PRINTING | |
| Print Technology | Fused deposition modeling (FDM) |
| Build Speed | Max Print Speed: Up to 100 mm/sec |
| Layer Resolution | Maximum Capability: 100 - 400 microns Print Mode tuned for: 200 microns to provide an optimal balance of high surface quality and quick print time |
| Maximum Build Volume | 150mm x 150mm x 150mm |
| Supported Materials | MakerBot PLA and Tough |
| Maximum Heated Build Plate Temperature | 100°C |
| Operating Volume | 45 dB |
| HARDWARE | |
| Print Heads | 1 (user replaceable) |
| Nozzle Diameter | 0.4 mm |
| Nozzle Material | Brass |
| Sensors | Filament Detection and Auto Load/Unload |
| Display | 71mm color touch screen |
| Build Plate | Heated with removable, flexible build surface |
| Build Surface | Grip Surface |
| Camera Resolution | 2 megapixels |
| Ambient Operating Temperature | 15°C to 30°C 10% to 70% RH non-condensing |
| Storage Temperature | 0°C to 55°C |
| Filter | Particulate Filter |
| SIZE & WEIGHT | |
| Product Dimensions | 433.4mm (H) x 423.1mm (W) x 365.0mm (D) |
| Product Weight | 11.8kg |
| Shipping Weight | 17kg |
| Shipping Box | 549mm (H) x 517mm (W) x 460mm (D) |
| MATERIAL SPOOLS | |
| Material Spools | 1.75mm |
| Spool Type | Sketch Material Spool |
| Spool Size | Weight = 1kg | Diameter = 203mm |
| System | Open Filament System |
| SAFETY & COMPLIANCE | |
| Directives | LVD,WEEE, RoHS, Packaging, RED |
| Safety Standards | IEC/ EN/ UL60950-1, IEC/ EN/UL 62368-1 |
| ELECTRICAL | |
| Power Requirements | 100-240VAC~ 50/60 Hz, 2.7-1.3A |
| Connectivity | USB flash drive, Ethernet, Wi-Fi |
| SOFTWARE | |
| Software Bundle | MakerBot Print, MakerBot Connect |
| File Types [Windowys Only] |
MakerBot (.makerbot), STL (.stl) [ SolidWorks (.sldprt, .sldasm), InventorOBJ (.ipt, .iam), IGES (.iges, .igs), STEP AP203/214 (.step, .stp), CATIA (.CATPart, .CATProduct), Wavefront Object (.obj), Unigraphics/NX (.prt), Solid Edge (.par, .asm), ProE/Creo (.prt, .prt., .asm, .asm.), VRML (.wrl), Parasolid (.x_t, .x_b) ] |
| CAD Plugins | SolidWorks, Autodesk Fusion 360, Onshape, Autodesk Inventor |
| Operating Systems | Windows (7, 10), Mac OS X (10.12+) NOTE: Does not support Mac Catalina |
