ANYCUBIC PHOTON M5S

671,00 €
Tasse incluse
Quantità

  • The newest resin printer from Anycubic’s Photon Mono M-series offers high printing speed, high resolution, and is the first consumer grade levelling-free printer.

    Highlights:
  • 10.1’’ 12K Screen
  • Leveling Free
  • 3X Print Speed
  • 12K Exquisite Details

    The Photon Mono M5s is the 12K resolution of its 10.1-inch screen, achieving a 19-micron X accuracy, with printing details as precise as a hair thickness.


    Print 3X Faster

    Photon Mono M5s is able to reach a 105mm/h average printing speed. It uses a high-speed release film able to lower the release force, which ensures a high printing success rate while reducing the release height and increasing the lifting speed.

    The 1st Consumer Grade Leveling-free

    A mechanical sensor on the cantilever arm detects the fit between the printing platform and the floating leveling module and automatically adjusts it based on the detection results. This eliminates the risk of leveling failure, improves printing success rate.


    Smart, Simple and Efficient

    Auto Device Check

    Through multiple tests on the connectivity of the exposure screen, mechanical detection module, and motor operation status, it quickly detects and troubleshoots hardware problems, ensuring smooth and non-destructive connections to help achieve printing success.

    Resin Detection

    In order to reduce printing failures caused by insufficient resin, the resin detection mode is preset to intelligently detect whether the amount of resin in the vat meets the printing requirements before printing. Minimizes print failures due to resin shortages.

    Prints Status Detection

    The prints status detection function will provide reminders for common failures like bottoming-out printing, significantly reducing waste of resin and time. It also can smartly analyze the causes of failures, and provides effective suggestions to ensure printing efficiency.


    AnyCubic App

    Popular sliced models/STLs available for you to experience 3D printing in just one touch. Task viewing ensures your printing process in control.

    Upgraded Anycubic Photon Workshop 3.1

    • Intelligent Mode: In the new version of slicing software Anycubic Photon Workshop 3.1, the"Intelligent Mode" option can intelligently match exposure parameters according to model details and size, reduce the risk of printing failure caused by improper parameter settings.
    • New Support Algorithm: The new support algorithm further improves the printing stability and success rate, reduces damage to the model surface, makes it easy to remove supports and bottom valves. Comprehensively improve the speed of punching and slicing, making slicing easier to use.


    In the Box


  • Construction an Technical Details
    Resin UV Light Type LED Matrix UV
    Resin Display resolution X 11520 pixel
    Resin Display resolution Y 5120 pixel
    Recommended Printing Speed Max 104,4 mm/h (
    Build Area 123 mm x 218 mm x 200 mm
    Installation Space / Requirements
    Total Mass Overall Dimensions 460 mm x 270 mm x 290 mm
    Total Weight 8.6 kg
    Max Power Consumption 100 W
    Voltage AC: V
    Equipment
    Touch Screen Yes
    Connection
    USB Port Yes
    WLAN Yes
    Accuracy
    Shipping

PN-29208
