• Power Requirements: 4 to 6 VDC*,
• Communication: Pulse-width modulation
• Gear material: Acetal copolymer
• Dimensions: 2.2 x 0.8 x 1.6 in (55.8x 19 x 40.6 mm) excluding servo horn
• Operating temp range: +14 to +144 °F (-10 to +50 °C)
• Torque: 38 oz-in @ 6 V

Additional Resources

Download	Details	More Info
	Propeller Spin Code to Center Servo - 843 bytes | updated: 26 Sep 2012 - 11:43 am
	Standard Servo BASIC Stamp Code - 2.82 KB | updated: 20 Sep 2012 - 2:52 pm
	Servo Dimensions - 75.19 KB | updated: 20 Sep 2012 - 2:50 pm
	Standard Servo Product Documentation - 147 KB | updated: 20 Sep 2012 - 2:49 pm
